Century Heating
Century HeatingSKU: CB00024
FW3500
Out of stock
Free Curbside Delivery.See Shipping & Delivery PolicyExtra-large firebox, ideal for large spaces and harsh climates
Full description
ALAIN'S ADVICE
Recommended for installation
These options allow you to get the most out of your appliance.
AC020815"Ø FRESH AIR INTAKE KIT
Out of stock
AC01099ASH DRAWER KIT
Out of stock
AC01281RIGID FIRESCREEN
Out of stock
Out of stock
AC02055QUICK CONNECT THERMODISC
Out of stock
AC03513TEG BLOWER - 4 BLADES BLACK
Out of stock
Accessories
Description
- Extra-large firebox, ideal for large spaces and harsh climates
- Reinforced appliance top with a C-Cast heat shield
- Cast iron door and ceramic glass
- EPA certified at 1.6 g/h
- Non-catalytic combustion system
- Designed and made in Canada
- Included: pedestal, ash lip, air intake damper and rear air deflector
Specifications
General features
Alcove installation approved
Yes
Mobile home approved
Yes, with fresh air intake
Certified according to applicable standards
CAN/USA accredited laboratory
Overall dimension (Width)
28 1/8"
Overall dimension (Height)
35 3/4"
Overall dimension (Depth)
31 1/4"
Premium quality blower included (CFM)
Optional
Combustion technology
Non-catalytic
Stainless-steel secondary-air system
Yes
Flue outlet diameter
6"
Distance-center of the flue outlet to back unit
9"
Distance-center of the flue outlet to side unit
14 1/8"
Recommended chimney diameter
6"
Type of chimney
CAN/ULC S629, UL 103 HT (2100 °F)
Minimum chimney height
12'
Door type
Single, glass with cast iron frame
Door opening size (Width)
19"
Door opening size (Height)
9 7/8"
Glass type
Ceramic glass
Glass surface - W x H
16 5/8" x 11 3/4"
Steel thickness-body
3/16"
Steel thickness-top
5/16"
Firebox size (Width)
22 7/8"
Firebox size (Height)
12 7/8"
Firebox size (Depth)
20 1/8"
Log positioning
Loading over width and over depth
Maximum log length
22" (16" recommended)
Firebox lined with refractory bricks
Yes
Baffle type
High quality vermiculite
High-efficiency certified appliance
Yes
Canadian Standard (emissions)
CSA B415.1-10
USA Standard (emissions)
EPA
Canadian Standard (safety)
ULC S627
USA Standard (safety)
UL 1482, UL 737
Warranty
Limited 5 years
Shipping weight
451 lb (205 kg)
Appliance performance
Fuel type
Dry cordwood
Recommended heating area(9)
1,000 - 2,700 ft²
Overall firebox volume
3.5 ft³
EPA loading volume
2.88 ft³
Maximum burn time(9)
10 h
Maximum heat output-dry cordwood(4)
110,000 BTU/h
Minimum overall heat output rate(4)(5)
17,200 BTU/h (5.0 kW)
Maximum overall heat output rate(4)(5)
57,800 BTU/h (16.9 kW)
Average overall efficiency-dry cordwood (HHV)(5)(6)
71%
Average overall efficiency-dry cordwood (LHV)(5)(7)
76%
Optimum efficiency(1)(2)
77%
Optimum heat transfer efficiency(8)
75%
Average particulate emission rate(3)
1.6 g/h
Average CO(10)
73 g/h
Clearances
Clearance
Single wall pipe
Double wall pipe
Back wall
13 3/4"
8"
Corner
12"
12"
Side wall
22"
19"
Base of the unit to ceiling
84"
84"
Manuals and Instructions
Consult the available manuals and leaflets for more information on performance, installation and use requirements, etc.
Frequently Asked Questions
Our stove and fireplace expert Alain answers your questions about this product.
