Century Heating
0
Century Heating
Century HeatingSKU: CB00021

FW2800

Out of stock

Free Curbside Delivery.See Shipping & Delivery Policy

Medium size firebox, ideal for all types of homes

Full description
24 1/4"L X 24 7/8"P X 32 3/8"H
500 - 1,800 ft²
18" (16" recommended)
2.4 g/h
Full specifications
Alain
ALAIN'S ADVICE
Description

  • Medium size firebox, ideal for tight spaces
  • Reinforced appliance top with a stainless steel heat shield
  • Cast iron door and ceramic glass
  • EPA certified at 2.4 g/h
  • Non-catalytic combustion system
  • Designed and made in Canada
  • Included: pedestal, ash lip, air intake damper, rear air deflector and stainless steel heat shield

Specifications

General features

Alcove installation approved
Yes
Mobile home approved
Yes, with fresh air intake
Certified according to applicable standards
CAN/USA accredited laboratory
Overall dimension (Width)
24 1/4"
Overall dimension (Height)
32 3/8"
Overall dimension (Depth)
24 7/8"
Premium quality blower included (CFM)
Optional
Combustion technology
Non-catalytic
Stainless-steel secondary-air system
Yes
Flue outlet diameter
6"
Distance-center of the flue outlet to back unit
7 1/2"
Distance-center of the flue outlet to side unit
12 1/8"
Recommended chimney diameter
6"
Type of chimney
CAN/ULC S629, UL 103 HT (2100 °F)
Minimum chimney height
15"
Door type
Single, glass with cast iron frame
Door opening size (Width)
17 1/4"
Door opening size (Height)
8"
Glass type
Ceramic glass
Glass surface - W x H
14 7/8" x 9 1/4"
Steel thickness-body
3/16"
Steel thickness-top
1/4"
Firebox size (Width)
19 5/8"
Firebox size (Height)
11 7/8"
Firebox size (Depth)
13 1/2"
Log positioning
Loading over width
Maximum log length
18" (16" recommended)
Firebox lined with refractory bricks
Yes
Baffle type
High quality vermiculite
High-efficiency certified appliance
Yes, EPA 2020 approved
Canadian Standard (emissions)
CSA B415.1-10
USA Standard (emissions)
EPA
Canadian Standard (safety)
ULC S627
USA Standard (safety)
UL 1482, UL 737
Warranty
Limited 5 years
Shipping weight
310 lb (141 kg)

Appliance performance

Fuel type
Dry cordwood
Recommended heating area(9)
500 - 1,800 ft²
Overall firebox volume
1.86 ft³
EPA loading volume
1.44 ft³
Maximum burn time(9)
7 h
Maximum heat output-dry cordwood(4)
65,000 BTU/h
Minimum overall heat output rate(4)(5)
9,800 BTU/h (2.87 kW)
Maximum overall heat output rate(4)(5)
52,200 BTU/h (15.3 kW)
Average overall efficiency-dry cordwood (HHV)(5)(6)
68%
Average overall efficiency-dry cordwood (LHV)(5)(7)
73%
Optimum efficiency(1)(2)
76%
Optimum heat transfer efficiency(8)
75 %
Average particulate emission rate(3)
2.4 g/h
Average CO(10)
103 g/h

Clearances

Clearance
Single wall pipe
Double wall pipe
Back wall
13"
7 1/2"
Corner
12"
12"
Side wall
15"
15"
Base of the unit to ceiling
84"
84"
