Ventis
VentisSKU: VB00004

ME150

Out of stock

Free Curbside Delivery.See Shipping & Delivery Policy

Designed mainly for ambiance

Full description
< 1,000 ft²
16"
Full specifications
Description

▪Designed mainly for ambiance
▪Generates enough heat in the event of a power failure
▪EPA exempt
▪Premium manufacturing quality
▪Molded refractory stones
▪Factory-installed doors and faceplate
▪Firescreen doors included
▪Cast iron reclining grate
▪7" Ventis stainless steel anchor plate included
▪Fresh air intake adapter included

Specifications

General features

Recommended chimney diameter
7"
Flue outlet diameter
7"
Firebox size (Height)
19"
Firebox size (Width)
19 5/8"
Firebox size (Depth)
14 1/4"
Overall dimension (Height)
40 5/8"
Overall dimension (Width)
40 1/4"
Overall dimension (Depth)
26 1/4"
Door opening size (Height)
14 1/4"
Door opening size (Width)
28 1/4"
High-efficiency certified appliance
EPA Standards exempt
Warranty
Lifetime limited
Minimum chimney height
15"
Maximum log length
16"
Canadian Standard (safety)
ULC S610
USA Standard (safety)
UL 127
Shipping weight
444 lb (201 kg)
Log positioning
Loading over width
Glass surface - W x H
28 3/4" x 16 1/2"
Combustion technology
Non-catalytic
Certified according to applicable standards
CAN/USA accredited laboratory
Type of chimney
ULC S604, ULC S629, UL 103 HT (2100 °F)
Door type
Double, glass with steel frame
Premium quality blower included (CFM)
Optional
Glass type
Ceramic glass

Appliance performance

Heating area(9)
< 1,000 ft²
Burn rate
> 5 kg/h (> 11 lb/h)
Fuel type
Dry cordwood
Overall firebox volume
3 ft³

Clearances

Clearance - Base of the unit to ceiling**84"84"Clearance - Combustible side mantle to unit0"0"Clearance - Combustible top mantle to unit0"0"Clearance - Combustible side wall to unit24"24"Clearance - Base of the unit to a combustible shelf48"48"
Manuals and Instructions

Consult the available manuals and leaflets for more information on performance, installation and use requirements, etc.
