Enerzone
0
Enerzone
EnerzoneSKU: EB00063-Bundle

SOLUTION 2.3

Out of stock

Free Curbside Delivery.See Shipping & Delivery Policy

Experience moments of pure happiness in the comfort of your own home with the enhanced performance of the Solution 2.3.

Full description
27"L X 26 1/2"P X 32 3/4"H
500 - 2,100 ft²
20"
2.3 g/h
Full specifications
Alain
ALAIN'S ADVICE
Customize your productSubtotal: 0
Description

Experience moments of pure happiness in the comfort of your own home with the enhanced performance of the Solution 2.3. Thanks to our state-of-the-art technology, the combustion process offers a high thermal output of 75,000 BTU/h and low emissions of 2.3 g/h. This model proves to be the key for the informed consumer for whom wood heating has no secrets as well as for the new owner wishing to explore the comfort of alternative heating. The size of the firebox permits the easy positioning of logs in both depth and width. Despite its size, the Solution 2.3 keeps a balanced design that gives it the look of a decorative appliance while providing powerful heating to the serious user.

Several versions of options are available to allow you to create a look that suits your needs. Choose from 3 leg models, in black or brushed nickel, and a pedestal, a variable speed 130 CFM fan, or a heat exchanger. The Solution 2.3 is the perfect balance between security, performance and comfort.

Specifications

General features

Alcove installation approved
Yes
Mobile home approved
Yes, with fresh air intake
Certified according to applicable standards
By an accredited laboratory (CAN/USA)
Overall dimension (Width)
27"
Overall dimension (Height)
32 3/4"
Overall dimension (Depth)
26 1/2"
Premium quality blower included (CFM)
Optional
Combustion technology
Non-catalytic
Stainless-steel secondary-air system
Yes
Flue outlet diameter
6"
Distance-center of the flue outlet to back unit
6 5/8"
Distance-center of the flue outlet to side unit
13 1/2"
Recommended chimney diameter
6"
Type of chimney
CAN/ULC S629, UL 103 HT (2100 °F)
Minimum chimney height
12'
Door type
Single, glass with cast iron frame
Door opening size (Width)
17 1/2"
Door opening size (Height)
9"
Glass type
Ceramic glass
Glass surface - W x H
16 5/8" x 10 5/8"
Steel thickness-body
3/16"
Steel thickness-top
3/8"
Firebox size (Width)
21"
Firebox size (Height)
11 7/8"
Firebox size (Depth)
16 1/2"
Log positioning
Loading over width
Maximum log length
20"
Firebox lined with refractory bricks
Yes
Baffle type
C-Cast or equivalent
High-efficiency certified appliance
Yes, EPA 2020 approved
Canadian Standard (emissions)
CSA B415.1-10
USA Standard (emissions)
EPA
Canadian Standard (safety)
ULC S627
USA Standard (safety)
UL 1482, UL 737
Warranty
Limited lifetime
Shipping weight
402 lb (182 kg)

Appliance performance

Fuel type
Dry cordwood (16" recommended)
Recommended heating area(9)
500 - 2,100 ft²
Overall firebox volume
2.4 ft³
EPA loading volume
1.95 ft³
Maximum burn time(9)
8 h
Maximum heat output-dry cordwood(4)
75,000 BTU/h (22.0 kW)
Minimum overall heat output rate(4)(5)
14,200 BTU/h (4.16 kW)
Maximum overall heat output rate(4)(5)
44,500 BTU/h (13.04 kW)
Average overall efficiency-dry cordwood (HHV)(5)(6)
72 %
Average overall efficiency-dry cordwood (LHV)(5)(7)
77 %
Optimum efficiency(1)(2)
79 %
Optimum heat transfer efficiency(8)
76 %
Average particulate emission rate(3)
2.3 g/h
Average CO(10)
69 g/h

Clearances

Canada
United States
Single wall pipe
Double wall pipe
Single wall pipe
Double wall pipe
Clearance - Back wall14 1/2"14 1/2"14 1/2"14 1/2"Clearance - Side wall17"17"17"17"Clearance - Corner10"10"10"10"Clearance - Base of the unit to ceiling**84"84"84"84"
Manuals and Instructions

Consult the available manuals and leaflets for more information on performance, installation and use requirements, etc.

Some questions? We can help you! Contact-us
Frequently Asked Questions

Our stove and fireplace expert Alain answers your questions about this product.
