Ventis
VentisSKU: VB00018-Bundle

HE325

Out of stock

Free Curbside Delivery.See Shipping & Delivery Policy

Designed mainly for heating

Full description
750 - 2,500 ft²
18"
9 h
0.99 g/h
Full specifications
Customize your productSubtotal: 0
Description

▪Designed mainly for heating
▪Large, high-efficiency fireplace among the most powerful on the market
▪Retractable double doors for an unrivaled experience
▪EPA 2020 certified
▪Non-catalytic combustion technology
▪Installation authorized on the Island of Montreal
▪Firestop made of high density insulation board
▪Ventis distinctive louvers
▪176 CFM blower included
▪Molded refractory stones
▪6" Ventis stainless steel anchor plate included
▪Fresh air intake adapter included

Required option: modern faceplate (VBA1570)

Specifications

General features

Baffle type
Ceramic panel
Recommended chimney diameter
6"
Flue outlet diameter
6"
Firebox size (Height)
16 7/8"
Firebox size (Width)
18 7/8"
Firebox size (Depth)
17"
Overall dimension (Height)
49 1/8"
Overall dimension (Width)
41 3/4"
Overall dimension (Depth)
28 7/8"
Door opening size (Height)
10 1/4"
Door opening size (Width)
20 3/4"
High-efficiency certified appliance
Yes, EPA 2020 approved
Warranty
Lifetime limited
Minimum chimney height
15"
Maximum log length
18"
Canadian Standard (emissions)
CSA B415.1-10
USA Standard (emissions)
EPA
Canadian Standard (safety)
ULC S610
USA Standard (safety)
UL 127
Moulded refractory panels
Yes
Shipping weight
530 lb (240 kg)
Log positioning
Loading over width
Glass surface - W x H
18 3/4" x 11"
Stainless-steel secondary-air system
Yes
Combustion technology
Non-catalytic
Certified according to applicable standards
CAN/USA accredited laboratory
Type of chimney
CAN/ULC S629, UL 103 HT (2100 °F)
Door type
Double, glass with cast iron frame
Premium quality blower included (CFM)
176 CFM included
Glass type
Ceramic glass

Appliance performance

Optimum efficiency(1)(2)
72 %
Average particulate emission rate(3)
0.99 g/h
EPA loading volume
2.61 ft³
Maximum heat output-dry cordwood(4)
85,000 BTU/h
Maximum overall heat output rate(4)(5)
49,654 BTU/h (14.55 kW)
Minimum overall heat output rate(4)(5)
18,057 BTU/h (5.29 kW)
Average overall efficiency-dry cordwood (HHV)(5)(6)
65.7 %
Average overall efficiency-dry cordwood (LHV)(5)(7)
70.8 %
Optimum heat transfer efficiency(8)
68 %
Recommended heating area(9)
750 - 2,500 ft²
Average CO(10)
50.1 g/h
Maximum burn time(9)
9 h
Fuel type
Dry cordwood (16" recommended)
Overall firebox volume
3.0 ft³

Clearances

Clearance - Base of the unit to ceiling**80"80"Clearance - Combustible side mantle to unit8"8"Clearance - Combustible top mantle to unitN/AN/AClearance - Combustible side wall to unit21"21"Clearance - Base of the unit to a combustible shelfN.A. or 48" non-combustibleN.A. ou 48" incombustible
