Ventis
0
Ventis
VentisSKU: VB00005-Bundle

HE350

Out of stock

Free Curbside Delivery.See Shipping & Delivery Policy

Designed mainly for heating large spaces

Full description
1,000 - 2,800 ft²
25"
11 h
1.6 g/h
Full specifications
Customize your productSubtotal: 0
Description

▪Designed mainly for heating large spaces
▪Patented design of the intelligent air control mechanism
▪Luxurious effect created by an eye-catching fireplace
▪Large glass surface
▪EPA 2020 certified
▪Non-catalytic combustion technology
▪Installation authorized on the Island of Montreal
▪Firestop made of high density insulation board
▪176 CFM blower included
▪8" Ventis stainless steel anchor plate included
▪Fresh air intake adapter included

Required option: traditional faceplate (VBA1540) and molded refractory bricks (AC02360)

Specifications

General features

Baffle type
High density insulation board
Recommended chimney diameter
8"
Flue outlet diameter
8"
Firebox size (Height)
25 3/8"
Firebox size (Width)
25 3/8"
Firebox size (Depth)
17 7/8"
Overall dimension (Height)
43 3/8"
Overall dimension (Width)
45 1/4"
Overall dimension (Depth)
31 3/4"
Door opening size (Height)
12 3/4"
Door opening size (Width)
33"
High-efficiency certified appliance
Yes, EPA 2020 certified
Warranty
Lifetime limited
Minimum chimney height
15"
Maximum log length
25"
Canadian Standard (emissions)
CSA B415.1-10
USA Standard (emissions)
EPA / ASTM WK47329
Canadian Standard (safety)
ULC S610
USA Standard (safety)
UL 127
Moulded refractory panels
No
Shipping weight
555 lb (252 kg)
Log positioning
Loading over width
Glass surface - W x H
29 3/4" x 13 1/2"
Stainless-steel secondary-air system
Yes
Combustion technology
Non-catalytic
Certified according to applicable standards
CAN/USA accredited laboratory
Type of chimney
CAN/ULC S629, UL 103 HT (2100 °F)
Door type
Double, glass with cast iron frame
Premium quality blower included (CFM)
176 CFM included
Glass type
Ceramic glass

Appliance performance

Optimum efficiency(1)(2)
70 %
Average particulate emission rate(3)
1.6 g/h
EPA loading volume
4.28 ft³
Maximum heat output-dry cordwood(4)
95,000 BTU/h
Maximum overall heat output rate(4)(5)
43,000 BTU/h (12.6 kW)
Minimum overall heat output rate(4)(5)
16,900 BTU/h (5.0 kW)
Average overall efficiency-dry cordwood (HHV)(5)(6)
64 %
Average overall efficiency-dry cordwood (LHV)(5)(7)
69 %
Optimum heat transfer efficiency(8)
69 %
Recommended heating area(9)
1,000 - 2,800 ft²
Average CO(10)
159.0 g/h
Maximum burn time(9)
11 h
Fuel type
Dry cordwood (16" recommended)
Overall firebox volume
4.28 ft³

Clearances

Clearance - Base of the unit to ceiling**84"84"Clearance - Combustible side mantle to unit8"8"Clearance - Combustible top mantle to unit84"84"Clearance - Combustible side wall to unit24"24"Clearance - Base of the unit to a combustible shelfN.A. or 52" non-combustibleN.A. ou 52" incombustible
Manuals and Instructions

Consult the available manuals and leaflets for more information on performance, installation and use requirements, etc.
